Electric- REDS Z8 Pro Gen3 ESC & Gen6 V8 1/8 Motor Combo (2200kV) (ROAR, EFRA, IFMAR)

COEG0002

ESC & Motor Combo Overview:

The REDS Z8 Pro Gen3 ESC & Gen6 V8 1/8 Motor Combo is engineered for racers who demand the highest level of performance, efficiency, and control. Combining a Gen6 brushless motor with the advanced Z8 Pro Gen3 ESC, this package provides unmatched power delivery and seamless tunability for serious competition. Fully homologated by EFRA, ROAR, and IFMAR, it’s ready for top-tier racing, including world championship events.



About the Brushless Combo



Next-Level Control With Z8 Pro Gen3 ESC

The Z8 Pro Gen3 ESC is a powerhouse designed for smooth and reliable performance in the most demanding racing applications. Equipped with a built-in communication protocol and integrated Bluetooth, it allows fast, precise tuning and firmware upgrades directly from your smartphone via the Reds Racing app. Its ultra-low resistance FET board ensures maximum efficiency, while the 32-bit CPU enhances responsiveness for ultimate driving control. Capable of handling up to 220 amps, it delivers incredible power in a compact, sleek design.



Advanced Power From The Gen6 V8 Motor

The Gen6 V8 4-pole brushless motor builds on REDS’ proven design with improvements in durability, thermal management, and smooth power delivery. It features a second sensor port for easier cable management and a sealed IP5X-rated case for superior dust protection. With no mechanical timing to adjust, the motor relies on ESC-based electronic timing for precision and consistency. Upgraded solder tabs, high-temperature wiring, and enhanced bearing protection provide long-term reliability, while its lightweight build improves acceleration and handling.

Competition-Ready Performance

This ESC and motor combo is not only powerful but also fully certified for official competition use. Approved by EFRA, ROAR, and IFMAR, the system is eligible for use in world-class racing, including the 1/8 World Championship. Designed for demanding racers, the REDS combo ensures consistent performance across all track conditions, offering the ultimate blend of innovation, durability, and competitive advantage. Whether you’re racing locally or preparing for international events, this combo sets the standard in 1/8-scale power systems.



Features:

Reds Racing Gen6 V8 4-pole 1/8 brushless motor

Reds Racing Z8 Pro Gen3 ESC

Integrated Bluetooth for wireless tuning

Smartphone control via Reds Racing app

Ultra-low resistance FET board for efficiency

32-bit high-performance CPU for responsiveness

Handles up to 220 amps of current

IP5X-rated sealed motor case for dust protection

No mechanical timing, ESC-controlled instead

EFRA, ROAR, and IFMAR approved for competition



Overview

ESC & Motor Combo Overview:

The REDS Z8 Pro Gen3 ESC & Gen6 V8 1/8 Motor Combo is engineered for racers who demand the highest level of performance, efficiency, and control. Combining a Gen6 brushless motor with the advanced Z8 Pro Gen3 ESC, this package provides unmatched power delivery and seamless tunability for serious competition. Fully homologated by EFRA, ROAR, and IFMAR, it’s ready for top-tier racing, including world championship events.



About the Brushless Combo



Next-Level Control With Z8 Pro Gen3 ESC

The Z8 Pro Gen3 ESC is a powerhouse designed for smooth and reliable performance in the most demanding racing applications. Equipped with a built-in communication protocol and integrated Bluetooth, it allows fast, precise tuning and firmware upgrades directly from your smartphone via the Reds Racing app. Its ultra-low resistance FET board ensures maximum efficiency, while the 32-bit CPU enhances responsiveness for ultimate driving control. Capable of handling up to 220 amps, it delivers incredible power in a compact, sleek design.



Advanced Power From The Gen6 V8 Motor

The Gen6 V8 4-pole brushless motor builds on REDS’ proven design with improvements in durability, thermal management, and smooth power delivery. It features a second sensor port for easier cable management and a sealed IP5X-rated case for superior dust protection. With no mechanical timing to adjust, the motor relies on ESC-based electronic timing for precision and consistency. Upgraded solder tabs, high-temperature wiring, and enhanced bearing protection provide long-term reliability, while its lightweight build improves acceleration and handling.



Competition-Ready Performance

This ESC and motor combo is not only powerful but also fully certified for official competition use. Approved by EFRA, ROAR, and IFMAR, the system is eligible for use in world-class racing, including the 1/8 World Championship. Designed for demanding racers, the REDS combo ensures consistent performance across all track conditions, offering the ultimate blend of innovation, durability, and competitive advantage. Whether you’re racing locally or preparing for international events, this combo sets the standard in 1/8-scale power systems.



Features:

Reds Racing Gen6 V8 4-pole 1/8 brushless motor

Reds Racing Z8 Pro Gen3 ESC

Integrated Bluetooth for wireless tuning

Smartphone control via Reds Racing app

Ultra-low resistance FET board for efficiency

32-bit high-performance CPU for responsiveness

Handles up to 220 amps of current

IP5X-rated sealed motor case for dust protection

No mechanical timing, ESC-controlled instead

EFRA, ROAR, and IFMAR approved for competition

Includes:

(1) Reds Racing Gen6 V8 1/8 Brushless Sensored Motor

(1) Reds Racing Z8 Pro Gen3 ESC

(1) Sensor Cable

Specifications:

ESC

Suggested Application 1/8

Motor Type Brushless Sensored

Input Voltage 2-4S LiPo (7.4-14.8V)

Continuous Current 220A

Burst Current -

Dimensions (LxWxH) 2.17x1.58x1.46in (55x40x37mm)

Weight -

BEC Voltage 6.0/7.4V (Adjustable)

BEC Continuous Current 6A

BEC Peak Current -

Motor Connector Bare Wire

Battery Connector Bare Wire

Programmable Yes

Motor

Suggested Application 1/8

Size 2200kV

Type Brushless Sensored

Voltage 2-4S LiPo

Adjustable Timing No

Watts -

Connector Solder Type

Dimensions -

Shaft Diameter 5mm

Weight -
